FINISHING: • Titanium Grey • Titanium Black • Brilliant Copper

FEATURES

• Fingerprint Sensor • Code Access • Smart Touchpad • Anti-Panic Design
• Fully-Automatic Lock • Dual Verification • Tempered Glass Design
• Child Lock • Physical Key Alert • Panel & Handle Ant-Prying Alarm
• Door Bell • USB Emergency Power Supply • Battery Power Supply
• Virtual Password • Voice Assistant • Physical Key • Key Tag

TECHNICAL SPECIFICATIONS:

• Fingerprint • PIN Code • Key Tag • Physical Key

SAFETY ALERT FUNCTION

• Alert (Speed & Response in 1ms)
• Trigger Alarm after 3 Continuous Authorization Failures, System Disable for 90 Seconds after 5 Failures
• Circuit Failure Alarm • Outside Forced Lock Alarm
• Installation Failure (False Alarm/Alert) • Anti-Prying • Anti-Panic Design
• Mortise Security Level (can’t be opened under 270m) • Low Battery Indicator

FINGERPRINT TECHNOLOGY

• Fingerprint Area (160 pixels)
• Fingerprint Algorithm Copyright
• V8 (Except EL600F)
• Identification Sensitivity (150ms | 1:1<4ms/fingerprint)
• False Acceptance Rate* (< 0.001%)
• False Reject Rate* (< 1.0%) • Fingerprint Image Resolution (508 dpi)
• Anti-False Finger Membrane • Identification Sensitivity (<0.8s)

DESIGN & APPEARANCE

• Fully Automatic Design: EL600 & EL600F • Lever Handle Design: ID 60
• Multi-Point Security Lock Mode
• Double Verifiable
• Mechanical Lock & Circuit Board Damage Countermeasures – Physical Key
• Damage Resistance
• Working Temperature: -10°C – + 55°C • Waterproof (IP64)
• External mechanical force (The lock housing can bear 6000N external force)
• Scratch proof surface treatment hardness ≥2H)
• Adaptability (Season, Weather & Environment)
• Humidity (%) (No condensation at 0-93% RH)
• Service Life (More than 1,000,000 times)
• Fingerprint • Password
• Physical Key
• 2 Keys • Methods of replacement (Replace the lock cylinder or return to the manufacturer’s configuration)
• Door Thickness Limit (40mm-100mm)
• Surface Processing (IMD)
• Mortise (304 Stainless Steel)

IN THE BOX

• Exterior Body • Interior Body • Mortise • Drilling Template
• Installation Accessories • User Manual • Warranty Card
• Key Tag (2 Cards) • Physical Key (2 Keys) • Mounting Plate
• Cleaning Pad

CAPACITY

• Face Recognition (Up to 20 – EL600F) • Fingerprint (Up to 100)
• Key Tag (Up to 100) • Pin-code (6 Digits) (Up to 100)
