Security Bookroom Door

The Doors are designed for secure rooms storing confidential papers, records and limited amount of cash and valuables.

Model

Class A
External Dimensions (mm)
2005(H) × 1100(W)

Clear Opening (mm)
1892(H) × 814(W)

Wall Opening (mm)
1962(H) x 1004(W)

Wall Thickness (mm)
200 (inclusive of Plastering)

Approx. Net Weight (kg)
318 (Door) and 20 (Gate)

Class B
External Dimensions (mm)
2005(H) × 1100(W)

Clear Opening (mm)
1892(H) × 814(W)

Wall Opening (mm)
1962(H) x 1004(W)

Wall Thickness (mm)
200 (inclusive of Plastering)

Approx. Net Weight (kg)
274 (Door) and 20 (Gate)

Product Benefits:

• Overall Door thickness of:
  – 124mm for Class A Door
  – 121mm for Class B Door
• The protective layer consists of a steel door plate of:
  – 12mm for Class A Door
  – 9mm for Class B Door
• Secured by 4 active front bolts with diameter of 32mm and full height fixed rear docking bolt.
• ⁠Both Doors are secured by a 3-wheel Keyless Combination Lock and a 8-lever double bitted Key Lock as standard. Both locks operated independently.
• The Keyless Combination Lock and KeyLock are protected by 2 relockers. Any forced attempt to dislodge the locks would activate these secondary locking devices and restricts the movement of the internal boltwork system.
• The relocker is further protected by drill resistant hard plates.
•  The door comes standard with a painted grey primer based finish.
